| OPERATION CLASS |
Class D |
| NUMBER OF CHANNELS |
01 |
| MAXIMUM POWER |
@ 14.4 VDC - 1 Ohm: 1200 Watts RMS
@ 14.4 VDC - 2 Ohms: 680 Watts RMS
|
| INPUT SENSITIVITY |
230mV |
| SIGNAL TO NOISE RATIO |
>90dB |
| FREQUENCY RESPONSE |
8Hz ~ 250Hz (-3dB) |
| CROSSOVER HIGH PASS (HPF) |
8Hz ~ 30Hz (-12dB/8ª) Variable |
| CROSSOVER LOW PASS (LPF) |
60Hz ~ 250Hz (-12dB/8ª) Variable |
| BASS BOOST |
Parametric, Freq.: 35Hz ~ 60Hz / Boost: 0 ~ +12dB |
| THERMAL MANAGEMENT |
Smart Cooler with 2 speed |
| INPUT IMPEDANCE |
10K Ohms |
| OUTPUT IMPEDANCE |
1 Ohm |
| PROTECTION SYSTEM |
Output overload, low and high power voltage |
| MIN. SUPPLY VOLTAGE |
9 VDC |
| MAXIMUM POWER SUPPLY VOLTAGE |
16 VDC |
| CONSUMPTION AT REST |
0.90A |
| MAXIMUM MUSIC CONSUMPTION |
55A |
| MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL |
110A |
| DIMENSIONS (H X W X D) |
7.24" x 2.13" x 6.97" |
| WEIGHT |
3.06lb |
